130w 150w 180w Co2 Laser Cutting Tube 160mm Length High Performance

130w 150w 180w Co2 Laser Cutting Tube 160mm Length High Performance

    • 130w 150w 180w Co2 Laser Cutting Tube 160mm Length High Performance
    • 130w 150w 180w Co2 Laser Cutting Tube 160mm Length High Performance
  • 130w 150w 180w Co2 Laser Cutting Tube 160mm Length High Performance

    Product Details:

    Place of Origin: Guangdong, China
    Brand Name: Taiyi
    Certification: CE Certification
    Model Number: C serie 60W

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: $110
    Packaging Details: carton
    Delivery Time: 5-8 work days
    Payment Terms: T/T, Western Union, MoneyGram, L/C
    Supply Ability: 10000 pieces
    Contact Now
    Detailed Product Description
    Certification: CE Condition: New
    Work Wavelength:: 10.6um Power: 60W / 80W 150W
    Keywords: Laser Protective Windows Quility: High Level
    Diameter: 60mm Keyword: Laser Tube
    Laser Type: Co2 Laser Cutting Machine Length: 160mm
    High Light:

    laser cutting machine parts

    ,

    laser cutting machine spare parts



    60w/80w/100w/130w/150w/180w Co2 Laser Tube Laser Cutting Tube For Co2 Laser Cutter



    Specification:

    Model Rated Power(W) Max Power(w) Length(mm) Diameter(mm) Catalyze
    JSD-50-700 40 50 700 50 Yes
    JSD-50-800 50 60 800 50 Yes
    JSD-50-1000 50 70 1000 50 Yes
    JSD-55-1000 50 70 1000 55 Yes
    JSD-55-1200 60 80 1200 55 Yes
    JSD-55-1250 60 80 1250 55 Yes
    JSD-60-1200 60 80 1200 60 Yes
    JSD-60-1250 60 80 1250 60 Yes
    JSD-80-1250 80 100 1250 80 Yes
    JSD-60-1600 80 110 1600 60 Yes
    JSD-80-1200 90 100 1200 80 Yes
    JSD-80-1400 100 120 1400 80 Yes
    JSD-80-1450 100 120 1450 80 Yes
    JSD-80-1600 130 150 1600 80 Yes
    JSD-80-1650 130 160 1650 80 Yes
    JSD-80-1800 150 180 1800 80 Yes
    JSD-80-2000 180 190 2000 80 Yes



    Product installation:

    1, first line the electrode, (+, -) is not wrong. CO2 laser (laser tube) installation instructions:
    2, installation of cooling water pipe, the installation method of water from the negative electrode, the positive water and meet the principle of falling out, and the interface can not leak. Sufficient water must be stored in the pre - storage water storage device. After water, the water cooling pipe must be used without air bubbles (must be viewed before each use). If the laser tube is vertically installed, please notice that there is no bubble at the top of the laser tube. When the bubble exists, it will cause damage to the laser tube if it runs.
    3, in order to maintain the good performance of the laser tube, please use a temperature controlled water cooler between 20-25 degrees Celsius. If the cooling water is unstable, the output power of the laser tube will be unstable.
    4, when the laser tube is installed, there is enough space between the high pressure end of the laser tube and any other metal surface. If the gap is too small, triggering the high pressure of the laser tube will cause fire to the metal surface, which will cause damage to the laser tube and even cause damage to other main components of the laser.
    5, it is suggested that an automatic inspection device be added to the cooling water circulation system of the laser tube, so as to prevent the laser tube from overheating due to the water failure. For details, consult the supplier of the laser machine.



    130w 150w 180w Co2 Laser Cutting Tube 160mm Length High Performance 0

    130w 150w 180w Co2 Laser Cutting Tube 160mm Length High Performance 1
