Product Details:
|
Product Name: | Laser Cleaning Machine | Application: | Graffiti/rust/wood/stone/paint/oxide Layer Cleaning |
---|---|---|---|
Power: | 50W/100W/200W/300W Optional | Laser Source: | JPT |
Machine Type: | Pulse | Laser Wavelength: | 1064 Nm |
Clean Way: | Non-touch Laser Cleaning | Cleaning Type: | Manual |
Function: | Metal Rust Surface Laser Cleaning | ||
Highlight: | laser machine accessories,laser machine parts |
Product Parameter | ||||
Model | TY-QX1019-50SC | TY-QX1019-100SC | TY-QX1019-200SC | TY-QX1019-300SC |
voltage | Standard AC220V±10%, 50/60Hz power adapter (output DC48V) | Standard AC220V±10%, 50/60Hz power adapter (output DC48V) | Standard AC220V±10%, 50/60Hz power adapter (output DC48V) | Standard AC220V±10%, 50/60Hz power adapter (output DC48V) |
Optional additional battery, 50W continuous operation for 2h | Optional battery 100W continuous operation for 80-90 minutes | Optional 200W battery for 80 minutes | Optional 300W battery for 60 minutes | |
Power | 50W | 100W | 200W | 300W |
Laser type | Fiber Laser | |||
Repetition frequency | 45-170KHz | 20-200KHz(adjustable) | 1-3000KHz(adjustable) | 1-3000KHz(adjustable) |
Fiber length | 1.5M | |||
Cooling type | Air Cooling | |||
Speed | 12000mm/s | 30000mm/s | ||
Cleaning Range | 0-100mm | 0-145mm | ||
Size | 210×118mm/163×265mm | 213*123mm/168*339mm | 268*135mm/191.5*445mm | |
Machine Weight | 7KG/9.6KG(Battery included) | 8.5KG/12KG(Battery included) | 12.5KG/17KG(Battery included) | 13.5KG/18.1KG(Battery included) |
Laser Head Weight | <0.75Kg | |||
Operating Mode | Handheld/Automation |
