Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available

Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available
Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available

Large Image :  Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available

Product Details:
Place of Origin: Guangdong, China
Brand Name: TAIYI
Certification: CE
Model Number: TY-HS6018
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Contact us for the price
Packaging Details: Export standard packing
Delivery Time: 7-20 work days
Payment Terms: T/T, Western Union, MoneyGram, L/C
Supply Ability: 500 pieces
Contact Now

Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available

Description
Certification: CE Condition: New
Warranty: 2 Year Applicable Material: Metal
Keywords: 6 Axis Welding Robot Custom: Accept
Highlight:

6-axis fiber laser welding machine

,

robot laser welding machine with cobot

,

fiber laser welder multiple sizes

Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available

Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available 0Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available 1Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available 2Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available 3

Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available 4

TECHNICAL GUIDANCE FOR ONTOLOGY



 Robotic Arm Parameters





































MaxArmspan

1077mm

Payload

7kg

Repeat Positioning

±0.02mm

ToolMax speed

3000mm/s

ControlBus/Freq

EtherCAT/1KHz

Rated power

260W

Temperature

-5~55℃

Humidity

5%~90%RH,non-condensing

Installation mode

Arbitrary angle

Protection Degree

IP65

weight

21kg

Noise level

≤60dB

Work port

1/0 Port

24V/18;DI:2D0:2AI

Tool Pot

COM Port

24V/1A;1RS485:1 EtherCAT
Joint Movement Parameters







Iotion Range

J1

-360°“360°

J2

-360°"360°

J3

-165°“165°

J4

-360°"360°

J5

-360°360°

J6

-360°“360°





Max Speed

J1

210°s

J2

210/s

J3

210°/s

J4

360°/s

J5

360°/s

J6

360°/s

Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available 5

TECHNICAL GUIDANCE FOR ONTOLOGY

TECHNICAL GUIDANCE FOR ONTOLOGY
Robotic Arm Parameters MaxArmspan 1460.7mm
Payload 6kg
Repeat Positioning ±0.05mm
ToolMax speed 3000mm/s
ControlBus/Freq EtherCAT/1KHz
Rated power 260W
Temperature -5~55℃
Humidity 5%~90%RH,non-condensing
Installation mode Arbitrary angle
Protection Degree IP65
weight 22kg
Noise level ≤60dB
  Work port 1/O Port 24V/1A;DI;2D0;2AI
  Tool Port COM Port 124V/1A;1RS485;1EtherCAT
Joint Movement Parameters Motion Range J1 -360°~360°
J2 -360°~360°
J3 -165°~165°
J4 -360°~360°
J5 -360°~360°
J6 -360°~360°
Max Speed J1 210°s
J2 210/s
J3 210°/s
J4 360°/s
J5 360°/s
J6 360°/s



Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available 6

TECHNICAL GUIDANCE FOR ONTOLOGY
Robotic Arm Parameters MaxArmspan 2027mm
Payload 20kg
Repeat Positioning ±0.05mm
ToolMax speed 4000mm/s
ControlBus/Freq EtherCAT/1KHz
Rated power 1500W
Temperature -5~55℃
Humidity 5%~90%RH,non-condensing
Installation mode Arbitrary angle
Protection Degree IP65
weight 68kg
Noise level ≤60dB
  Work port 1/O Port 24V/1A;DI;2D0;2AI
  Tool Port COM Port 124V/1A;1RS485;1EtherCAT
Joint Movement Parameters Motion Range J1 -360°~360°
J2 -360°~360°
J3 -165°~165°
J4 -360°~360°
J5 -360°~360°
J6 -360°~360°
Max Speed J1 180°s
J2 180°s
J3 210°/s
J4 270°/s
J5 270°/s
J6 270°/s



Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available 7
Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available 8

Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available 9Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available 10Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available 11Hot Sale Fiber Laser Welding Machine with 6-axis Collaborative Cobot ,Multiple Sizes Are Available 12
