IPG 20KW 20000W YLS-20000-RI Series Fiber Laser Source for CNC Metal Fiber Laser Cutting Machine

Large Image : IPG 20KW 20000W YLS-20000-RI Series Fiber Laser Source for CNC Metal Fiber Laser Cutting Machine

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	TAIYI
Certification:	CE
Model Number:	YLS-20000-RI

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Contact us for the price
Packaging Details:	Export standard packing
Delivery Time:	5-8 work days
Payment Terms:	T/T, Western Union, MoneyGram, L/C
Supply Ability:	500 pieces per month

Contact Now

IPG 20KW 20000W YLS-20000-RI Series Fiber Laser Source for CNC Metal Fiber Laser Cutting Machine

Description

Certification:	CE	Condition:	New
Application:	Fiber Laser Cutting Machine	Laser Type:	Fiber Laser
Wavelength:	1070nm	Brand:	IPG
Power:	20000W
Highlight:	20KW fiber laser source , metal cutting laser source , CNC laser source with warranty

IPG 20KW 20000W YLS-20000-RI Series Fiber Laser Source for CNC Metal Fiber Laser Cutting Machine 0

IPG 20KW 20000W YLS-20000-RI Series Fiber Laser Source for CNC Metal Fiber Laser Cutting Machine 2

1. Optical characteristics

N	Characteristics	Test conditions	Symbol	Min.	Typ.	Max.	Unit
1	Operation Mode			CW / Modulated
2	Polarization			Random
3	Nominal Output Power*		Pnom	20			kW
4	Output Power Tuning Range, lower limit**	Relative to Pnom			5		%
5	Output Power Tuning Range, upper limit	Relative to Pnom		100		105	%
6	Emission Wavelength	Output power: 20 kW	λ	1068	1070	1080	nm
7	Emission Linewidth		Δλ		5	8	nm
8	Switching ON/OFF Time				30	50	μs
9	Output Power Modulation Rate					10	kHz
10	Output Power Instability	Output power: 20 kW Time interval: 1 hour (T=Constant)			±1	±2	%
11	Red Guide Laser Power				0.4	0.5	mW

External layout

IPG 20KW 20000W YLS-20000-RI Series Fiber Laser Source for CNC Metal Fiber Laser Cutting Machine 3

IPG 20KW 20000W YLS-20000-RI Series Fiber Laser Source for CNC Metal Fiber Laser Cutting Machine 4
